NZXT ( NZXT H710 White Case )

NZXT H710 White Case

DIMENSIONS

W: 230mm H: 516mm D: 494mm (with feet)

MATERIAL(S)

SGCC Steel and Tempered Glass

WEIGHT

12.1 kg

MOTHERBOARD SUPPORT

Mini-ITX, MicroATX, ATX and EATX (Up to 272mm or 10.7-inches)

FRONT I/O PORTS

1x USB 3.1 Gen 2 Type-C

 2x USB 3.1 Gen 1 Type-A

 1x Headset Audio Jack

  Front I/O internal header

 1x USB 3.1 Gen 2 Internal Header

 1x USB 3.1 Gen 1 Internal Header

 1x HD Audio Header

FILTERS

All Air Intakes

INCLUDED ACCESSORIES

Installation screws

 10x Cable ties

 1x Headset Audio Jack Splitter (4 pole to 3 pole)

EXPANSION SLOTS

7

DRIVE BAYS

2.5”: 7

 3.5”: 2+2

RADIATOR SUPPORT

Front: 2x 140 or 3x 120mm with Push/Pull

 Top: 2x 140 or 3x 120

 Rear: 1x 120

FAN SUPPORT

Front: 3x 120/ 2x 140mm (3 Aer F120 Case Version included)

 Top: 3x 120/2x 140mm

 Rear: 1x 120/1x 140mm (1 Aer F140 Case Version included)

FAN SPECS

Aer F120 (Case Version)

 Speed: 1200 ± 200 RPM

 Airflow: 50.42

 CFM Noise: 28 dBA

 Bearing: Rifle Bearing

  Aer F140 (Case Version)

 Speed: 1,000 ± 200 RPM

 Airflow: 68.95 CFM

 Noise: 29 dBA

 Bearing: Rifle Bearing

CLEARANCE

Cable Management: 18-22mm

 GPU Clearance: Up to 413mm

 CPU Cooler: Up to 185mm

 Front Radiator: 60mm

 Top Radiator: 30mm

 Reservoir & Pump: Up to 224mm (Along cable bar)
